6 LCI/USB Installation Instructions TG200817 Issue 2 20/03/2009
LCI/USB Installation Instructions
3 INStaLLatION
(continued)
parameter Default Function Only change if
R(..address L - own address 19 Device address of LCI if more than 1 LCI being
used
N - own LaN 1 Lan number of LCI if more than 1 LCI being
used
D - identifier “LCI” Identifier attribute of LCI For alarm ident
r - L ON W ORKS
retry time
750 mS Time (mS) between message
retransmission following
non-acknowledgement.
See Trend LonWorks
Products Engineering
Manual for details
i - L ON W ORKS
interpacket delay
75 mS Time (mS) between frames of
data in a multi-frame message.
a - L ON W ORKS
service class
2 Defines whether messages
are repeated and whether
acknowledgements are expected.
2 specifies acknowledgement
and repeat if not acknowledged
up to three times.
b - L ON W ORKS
Buffer size
146 Specifies the size of
message frames in bytes
sent on LON.
If routers separate IQLs,
LINCs, LONCs and have
buffer size smaller that 146
bytes - set to smallest buffer
size. (min = 66)
m - L ON W ORKS
Message code
64 Code number used by IQLs,
LINCs, LONCs, all LINCs/
LONCs must use same code.
If message code being
used by other users - must
be exclusive to IQ System.
v - Native
messaging
0 Setting to 1 enables LCI to
send and receive L ON W ORKS
message frames in encoded
format. 0=disabled, 1=enabled.
If using with special native
messaging software tools.
p - Send service
PIN
0 Setting to one causes LCI to
send service PIN message to
Lon and set itself back to 0.
To generate message to
install on LMT, or to identify
LCI to system.
M - LON
T e r m i n a t o r
State
O Setting to I turns on the LCI’s
LON terminator
Only turn ON if experiencing
communications problems.
The Lon terminator can also
be turned ON by pressing
the Lon Terminator button.
TARP I Setting to O turns TARP
OFF
Set to O in most situations.
If there is one or more,
LINC or LNC2 on the Lon
section, there could be IQs
on attached Lan(s) and their
addresses can only be found
by using TARP and so TARP
should be set to I. LCIs,
LINCs and LNC2s which
do not share the same Lon
section do not need TARP, so
TARP should be set to O
z - Reset Node
Flag
When set to 1 the LCI resets
and clears the node status
and comms statistics. When
set to 2 the node status and
comms statistics are cleared.
Set to required value to
reset information.
Configure LCI
(if required)
