3 - 2 IQ22x Series Contollers Installation Instructions TG200001 Issue 1/G 08/05/06
IQ22x Installation Instructions - Options
1
Drill Wall
2
560 mm
560 mm
Open Door
3.4 Mounting in an Enclosure, ENCLs/...
3
Mount on Wall
OR
No. 12
b a
4
Remove Backplate Mount IQ22x on Backplate
5
M6
M6
6
Replace Backplate
3.5 Replacing the Battery
b
a
c
2
Switch Off
O
I
Upload Strategy
1
SET Manual TE200147
OR
1 2 3 4 5 6 7 8 9 1 0
A
B
C
D
9 'D type'
Female
Cable/EJ101442 RJ11
IQ22x
SET
IQ22x
X.IQ2
See above, "3.2 Connecting PC using
Supervisor Port"
A
D
D P
C
B
1 2 3 4 5 6 7 8 9 1 0
O
I
Isolate I/O, Network
3
WARNING: T h e
connecting
leads may be
connected
to supplies.
Isolate before touching.
Open Panel
4
T X R X L A N L A N 1 2 3 4 5 6 7 8 9 1 0 1 1 1 2 1 3 1 4 1 5 V 2 4 V 1 6 1 7 1 8 1 9 2 0
IQ22x/USA only
The unit is UL rated as 'UL916,
listed open energy
management equipment'
WARNING: Opening the panel
may exposes
dangerous voltages.
417-IEC-5036
Open MBOX
5
if unit fitted in ENCLS/MBOX/IQ22x
b
a
Open Flap
6
b
a
WARNING: Removal of
the cover
e x p o s e s
dangerous
voltages.
417-IEC-5036
