BRIEF LP LEVELS TEST DESCRIPTIONS
Name Purpose
VOH-Dp
To verify that the Thevenin Output High Level Voltage (VOH) of the DUT’s Data & Clock Lanes LP
transmitter is within the conformance limits.
VOH-Dn
VOH-CLKp
VOH-CLKn
VOL-Dp
To verify that the Thevenin Output Low Level Voltage (VOL) of the DUT’s Data & Clock Lanes LP
transmitter is within the conformance limits.
VOL-Dn
VOL-CLKp
VOL-CLKn
 With LP Rise & Fall selected in the Category field, the following Measure values are available:
TRLP-Dp, TRLP-Dn, TRLP-CLKp, TRLP-CLKn, TFLP-Dp, TFLP-Dn, TFLP-CLKp, and TFLP-CLKn.
Note: As mentioned previously in this section, when this category is selected, Dn-VOH, Dn-VOL, and
Find Levels controls are also shown. Provide values for the additional fields or use the Find Levels
button as desired.
BRIEF LP RISE & FALL TEST DESCRIPTIONS
Name Purpose
TRLP-Dp
To verify that the 15%-85% Rise Time (TRLP) of the DUT’s Data & Clock Lanes LP transmitter is
within the conformance limits.
TRLP-Dn
TRLP-CLKp
TRLP-CLKn
TFLP-Dp
To verify that the 15%-85% Fall Time (TFLP) of the DUT’s Data & Clock Lanes LP transmitter is
within the conformance limits.
TFLP-Dn
TFLP-CLKp
TFLP-CLKn
 With LP Timing selected in the Category field, the following Measure values are available:
TLP-PER-Data-500, TLP-PER-Data-930, TLP-PULSE-Data-500, TLP-PULSE-Data-930, FIRST-TLP-PULSE-Data-
500, FIRST-TLP-PULSE-Data-930, LAST-TLP-PULSE-Data-500, and LAST-TLP-PULSE-Data-930.
