Instruction Manual
922664 Rev A 9
Search Waveform
Choosing Search on the Decode Setup dialog opens a Zoom of the original decoded waveform and
displays the corresponding Zoom dialog with the standard rescaling controls.
Use the Zoom dialog Rescale controls to reposition the Zoom trace; use the Search dialog controls to
enter the search criteria.
Configure the following to specify the search criteria for SENT decodes:
Column to Search - Result table column to search for values.
Left/Right Pad - Percentage of horizontal division surrounding a found item to display.
Use the navigation buttons to find the next event that matches your search criteria:
Prev(ious) navigation buttons (top to bottom): go to previous occurrence of field or value; go to first
matching occurrence of field or value; scroll decoded signal from current point to beginning of decode;
pause scrolling.
Next navigation buttons(top to bottom): go to next occurrence of field or value; go to last matching
occurrence of field or value; scroll decoded signal from current point to end of decode; pause scrolling.
