1. Introduction
The ST Automated Test Suite is a turnkey verification system that allows developers to pre-test
devices for SAS/SATA specification conformance. The system generates specific traffic conditions to
the Host or Device under Test (DUT). The Analyzer simultaneously records and analyzes responses.
The ST Automated Test Suite includes a software console that manages the entire compliance
verification process by allowing users to run individual test cases or run the full suite in batch mode
operation.
The ST Automated Test Suite operates on Sierra M6-4, Sierra M6-2 and Sierra M6-1 platforms.
1.1 Test Case Overview
Each individual test case is controlled by a VB script that automates operation of the hardware and
software. The ST Automated Test Suite has Available VB Scripts:
o
General, such as PreemphasisLoad and VSE
o
Analyzer, such as Multi-Open-Close, Run Analyzer project (Make recording), and Run Analyzer
project (Start-stop recording)
o
Target Emulator, such as Activate-Deactivate and Analyzer-Target
o
Host Emulator, such as AnalyzerExerciser and HostOnly
o
Infusion, such as Analyzer-Infusion and Infusion
o
Trainer, such as Analyzer-Trainer, Analyzer-Trainer - 1 Port, Analyzer-Trainer - 2 Ports, Trainer
Only, and TrainerWithExitCode
o
Mixture Configurations, such as AnalyzerDeviceInfusion, AnalyzerHostDevice, HostInfusion,
TargetInfusion, TrainerInfusion
See
Chapter 4, Writing ATS VB Scripts
1.2 Folder Structure
The ST Automated Test Suite application has its own folder structure. These folders are at the top
level:
o
Examples/Scripts: Contains VB scripts.
o
Reports: Contains the generated reports.
o
Output: Default folder for saving trace files. You can change the default folder in the
