2
CATC BPT 1.00 C HAPTER 1
User’s Manual Introduction
• BPT application installation CD
• BPT User’s Manual on CD
• CATC Scripting Language User’s Manual on CD
1.4 Bluetooth Specification
Please refer to the Bluetooth Specification, version 1.1, for details on the Bluetooth wireless
technology protocol. The Bluetooth Specification is available from the Bluetooth SIG at its
web site: http://www.bluetooth.com.
1.5 Hardware Specifications
Package
Dimensions: 3.4 x 2.6 x 1.0 inches (8.6 x 6.6 x 2.5 centimeters)
Connectors: Host connection (USB, type B)
Audio connection (2.5 mm audio stereo jack)
Weight: 3.0 ounces (84g)
Environmental Conditions
Operating Range: 0 to 55 °C (32 to 131 °F)
Storage Range: -20 to 80 °C (-4 to 176 °F)
Humidity: 10 to 90%, non-condensing
Host Compatibility
Works with any PC equipped with a functioning USB port and running a Microsoft®
Windows® 98 SE, Windows 2000, Windows Me, or Windows XP operating system.
Hardware Interfaces
• Connects to the host computer via a standard USB interface
• 2.4 GHz (ISM band) external antenna
• 2.5 mm audio stereo jack
Radio
• Bluetooth version 1.1 qualified
• Class 2 designation with +4dBm transmit power and <-70 receiver sensitivity
• FCC and CE compliant
