HFP2500 High Frequency Probe
18 922253-00 Rev A
Replacement Parts
The probe connection accessories and other common parts can be ordered through the regional
customer care centers. Refer to list below for Teledyne LeCroy part numbers. Defective probes can
be replaced on an exchange basis. The replacement exchange probe will have been factory repaired,
inspected and calibrated to the same standards as a new product. In order to obtain an exchange
probe, you must return the defective probe. The returned probe should be sent back to the regional
customer care center without any accessories, manual or case.
Table 1: Replaceable Parts List
Item Teledyne LeCroy P/N Replacement QTY
Wire Assembly, Black PACC-LD005 1
Mini Clip, Black PK006-4 2
Micro Clip PACC-CL001 2
Socket Cartridge Assembly PACC-MS002 1
Low C Cartridge Assembly PACC-MS003 1
Short Right Angle Lead PACC-LD003 1
Long Right Angle Lead PACC-LD004 1
Square Pin Ground Spring PACC-LD002 1
IC Lead Tip PACC-PT003 4
SMD Discrete Tip PACC-PT004 4
Straight Tip PACC-PT001 4
Sharp Tip PACC-PT002 4
Bent Sharp Tip PACC-PT005 4
Leaf Pogo Ground Assembly PACC-CD009 1
Pogo Ground Lead PACC-CD008 2
Pivot Ground Lead PACC-CD007 2
FreeHand Probe Holder PACC-MS001 1
Soft Accessory case SAC-01A 1
Instruction Manual 922253-00 1
Certificate of Calibration 922415-CC 1
