System Sensor ZC20 User Manual
Zonecheck flow switch tester, Installation and maintenance instructions

D770-32-00
1
I56-0053-003R
Zonecheck
Flow Switch Tester
INSTALLATION AND MAINTENANCE INSTRUCTIONS
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
www.systemsensor.com
Important
Please Read Carefully And Save
This instruction manual contains important information about the instal-
lation and operation of a Zonecheck Flow Switch Tester. Purchasers who
install waterflow detectors for use by others must leave this manual or a
copy of it with the user.
Read all instructions carefully before beginning. Follow only those instruc-
tions that apply to the model you are installing.
Use Zonecheck Flow Switch Testers in wet-pipe systems only. Do NOT use
them in dry pipe, deluge, or preaction systems.
Do not use in potentially explosive atmospheres. Do not allow unused
wires to remain exposed.
Principles Of Operation
Retrofit Model
Zonecheck Flow Switch Tester shall mount on any clear steel pipe span of
the appropriate nominal size, either in a vertical upflow or horizontal run,
between 6″ and 12″ from the flow switch. Flow Switch Tester shall consist
of a recirculating pump, operating at nominal 110V or 220V as appropriate,
two (2) sets of valves and elbows to facilitate the circulation of the water,
a System Sensor vane-type waterflow detector, and a key switch to activate
the recirculating pump. When activated, the pump shall circulate the water
within the sprinkler riser around the waterflow detector vane to simulate
the flow of one sprinkler head in operation. The activating key switch shall
provide the means to be wired locally to one Flow Switch Tester, or inter-
connected with other key switches for group activation. Flow Switch Tester
shall be available for manifold and retrofit installation applications.
Manifold Model Specifications
Zonecheck Flow Switch Tester manifold models shall consist of a sched-
ule 10 pipe assembly of the appropriate nominal size. Manifold assembly
CAUTION
Specifications
Static Pressure Rating:
175 PSI
Operating Temperature Range: 32°F–120°F (0°C–49°C)
Compatible Pipe
(Manifold Models):
Schedule 10, 2″–4″ diameter
Compatible Pipe
(Retrofit Models):
Schedule 10 and 40, 2″–8″ diameter
(50 mm through 200 mm)
Service Use:
Inspection, Testing and
Maintenance of Water-Based
Fire Protection Systems: NFPA 25;
National Fire Alarm Code: NFPA 72
Manifold Assembly Length
(Manifold Models):
25.6″ (65 cm)
Component Connections:
Manifold Models:
Retrofit Models:
2 ea. - 1″ NPT/25mm
2 ea. - 1″ NPT/25mm British Standard
British Standard
Thread elbows
Thread elbows
2 ea. - 25mm British Standard
Thread elbows
Valves:
Red: Standard valve
Green: Contains check valve
Warranty: 3 years
shall provide grooved ends for accepting the appropriate grooved connec-
tion fittings. Manifold assembly shall include no less than two drain ports
with the appropriate drain plugs. Manifold Zonecheck models shall come
with the pump, valves, elbows, pipe assembly, drain plugs, and System
Sensor waterflow detector pre-assembled.
Manifold Models
Domestic Models with 110 V Pump
Canadian Models with 110 V Pump
ZC20, ZC25, ZC30, ZC40
ZC20A, ZC25A, ZC30A, ZC40A
Retrofit Models
Domestic Models
Canadian Models
International Models
with 110 V Pump
with 110 V Pump
with 220 V Pump
ZCR20
ZCR20A
ZCR20E
ZCR25
ZCR25A
ZCR25E
ZCR30
ZCR30A
ZCR30E
ZCR40
ZCR40A
ZCR40E
ZCR60
ZCR60A
ZCR60E
ZCR80
ZCR80A
ZCR80E
Replacement Parts
ZCK-1 Zonecheck 110V Keyswitch
ZCK-1E Zonecheck 220V Keyswitch
ZCP-110 Zonecheck 110V Pump
ZCP-220 Zonecheck 220V Pump
Do NOT install Zonecheck on copper piping.
General Installation Recommendations
Before installing any waterflow-related device, be thoroughly familiar
with: NFPA 72: National Fire Alarm Code
NFPA 13: Installation of Sprinkler Systems, Section 3.17
NFPA 25: Inspection, Testing and Maintenance of Sprinkler Systems
CAUTION
Electrical Specifications
Pump Operating Voltages:
Domestic/Canadian models:
1.63A@110 V, 60 Hz
International models: .88A@220 V, 50Hz
Key Switch Operating Voltage: ZCK-1 110V, 60Hz; ZCK-1E: 220V, 50Hz
Key Switch Mounting Options: Includes back box for surface or flush
mounting. For pre-wiring, use a
4
11
/
16
″ x 4
11
/
16
″ back box
Key Switch Operation Modes: Self-test: Wired locally
Group test: Interconnected
Key Switch LED Operation:
Ready state: No LED
Test Initiation: Green LED
Flow switch activation: Red LED
