Slc(–), Slc(+), Slot – System Sensor B224RB User Manual
Page 3: Comm.(+) comm.(–), Short delay
SS-450-003
3 I56-3737-002R
C0890-01
LISTED COM
PA
TIBLE CONTROL
P
ANEL
CLASS A OPTIONAL WIRING
2 RELAY COMMON
1 NORMALLY CLOSED
3 NORMALLY OPEN
(+)
(–)
(+)
(–)
OTHER INTELLIGENT
DEVICES
SLC(–)
Comm.(+)
Comm.(–)
SLC(+)
5(+) 4(–)
3(NO)
1(NC)
2(Common)
figUre 4. Wiring diagram:
PLASTIC LEVER
BREAK TAB AT
DOTTED LINE BY
TWISTING TOWARD
CENTER OF BASE.
USE SMALL-BLADED
SCREWDRIVER TO
PUSH PLASTIC LEVER
IN DIRECTION OF
ARROW.
figUre 5a. aCTiVaTing The TamPer-reSiST feaTUre:
SHORT
DELAY
C0144-00
figUre 5B. remOVing The deTeCTOr head frOm The BaSe:
figUre 6: reLaY aCTiVaTiOn ShUnT:
C1082-00
C1088-00
SLOT
SLOT
