B136SPK1 ¼" Facia Front Enclosure Kit
RS1200001 58 November 1996
Parts List
Part Number Description Quantity
12115803 Right cabinet extrusion 1
12128401 Cabinet extrusion 2
12200901 Cabinet bracket 2
12098007 Decorator panel bracket 2
12098005 Decorator panel bracket 2
M0215318 Small screw 10
M0210417 Small screw 7
M0223729 Small screw 58
12118504 Left cabinet extrusion 1
12064304 Toe grille 1
12064404 Toe grille 1
12116503 Installation Instructions 1
12119604 Door bracket shim 8
12119605 Door bracket shim 4
12119602 Cabinet bracket shim 8
Introduction
To avoid severe personal injury or property
damage from refrigerator tipping over, do not
open more than one door at a time, until
refrigerator has been secured to structure.
Recognize this symbol as a safety
precaution.
WARNING
Caution
To avoid property damage, protect soft vinyl
or other flooring with cardboard, rugs, or other
protective material.
Caution
To avoid personal injury, wear gloves to
protect hands and arms. Trim pieces may
have sharp edges.
Read entire manual before installing kit. Align parts
checking for proper fit before beginning. All necessary
tools and materials must be available prior to
installation. Verify all listed parts are included in kit. If
parts are missing, contact source from whom kit was
purchased.
• Two people are recommended to install kit.
• Mechanical experience is required to install kit.
• If unable to solve a problem during installation,
contact an authorized Amana technician. Locate
a Factory Service Center or independent
authorized technician by calling 1-800-628-5782
inside U.S.A. and 1-319-622-5511 outside U.S.A.
Service is at owner’s expense.
This kit is designed for applications requiring a 1/4"
wood side panel be attached to one or both sides of the
refrigerators. Kit may also have a 3/4" wood panel
attached to the base panel to bring the side panel to full
refrigerator depth. Kit includes trim and parts needed to
attach panel to the side of refrigerator.
