Amana Bottom Mount Refrigerator User Manual

Page 51

B136CKR1 and B136CKL1 Custom Handle Kit

November 1996

RS1200001

ntroduction

Parts List

To avoid severe personal injury or property
damage from refrigerator tipping over, do not
open more than one door at a time, until
refrigerator has been secured to structure.

Recognize this symbol as a safety
precaution.

WARNING

To avoid property damage, protect soft vinyl
or other flooring with cardboard, rugs, or other
protective material.

Read entire manual before installing kit. Align parts
checking for proper fit before beginning. All necessary
tools and materials must be available prior to
installation. Verify all listed parts are included in kit. If
parts are missing, contact source from whom kit was
purchased.

• Two people are recommended to install kit.
• Mechanical experience is required to install kit.
• If unable to solve a problem during installation,

contact an authorized Amana technician. Locate
a Factory Service Center or independent
authorized technician by calling 1-800-628-5782
inside U.S.A. and 1-319-622-5511 outside U.S.A.
Service is at owner’s expense.

Caution

To avoid personal injury protect hands and
arms by wearing gloves. Trim pieces may
have sharp edges.

Caution

This kit is designed for applications where custom
handles are desired to replace factory installed handles.
Kit includes trim necessary to hold custom panels in
place on refrigerator door and freezer drawer. Custom
handles are not provided and is the responsibility of the
consumer to provide.

B136CKR1

B136CKL1

Part Number

Description

Quantity

12063501

Extrusion freezer door frame

12063503

Extrusion door frame

12116501

Installation Instructions

M0275148

" Wide double back tape

12063703

Handle insert
