SX243: Parts Breakdown & Operating Manual 1 Rev. 09/20/11
Collet Opening ...........0.401" (10.19mm)
Blows per Minute .................2,200 BPM
Bore Diameter.....................3/4" (19mm)
Piston Stroke ............. 3-3/4" (95.25mm)
Weight ........................ 4.6 Lbs. (2.09 kg)
Length ........................8.88" (225.55mm)
SX243
Heavy
duty long
barrel air
Hammer
witH quick
cHange cHiSel
retainer
Average Air
Consumption .............. 4 CFM (91 l/min)
Air Inlet .....................................1/4" NPT
Minimum
Hose Size .....................3/8" I.D. (10mm)
Sound Level ..............................110 dBA
SPECIFICATIONS
AVOID PROLONGED EXPOSURE TO VIBRATION
WEAR HEARING PROTECTION
ALWAYS WEAR SAFETY GOGGLES
ALWAYS READ INSTRUCTIONS BEFORE
USING POWER TOOLS
WARNING
Operating Instructions • Warning Information • Parts Break down
