SX108A: Parts Breakdown & Operating Manual 4 Rev. 06/30/10
SX108A
3/8" Drive air ratchet wrench
Ref. # Item # DESCRIPTION QTY
1 RS108A01 Air Inlet 1
2 RS108A02 Handle 1
3 RS108A03 Throttle Bushing 1
4 RS108A04 Throttle Valve 1
5 RS108A05 O-Ring 1
6 RS108A06 Spring 1
7 RS108A07 O-Ring 1
8 RS108A08 Valve Screw 1
9 RS108A09 Throttle Lever 1
10 RS108A10 Lever Pin 1
11 RS108A11 Bearing Cap 1
12 RS108A12 Ball Bearing 1
13 RS108A13 Rear Plate 1
14 RS108A14 Dowel Pin 1
15 RS108A15 Rotor 1
16 RS108A16 Rotor Blade 4
17 RS108A17 Cylinder 1
18 RS108A18 Front Plate 1
19 RS30524 Ball Bearing 1
20 RS108A20 Washer 1
21 RS108A21 Internal Gear 1
22 RS108A22 Planet Gear 3
23 RS108A23 Planet Pin 3
Ref. # Item# DESCRIPTION QTY
24 RS108A24 Planet Cage 1
25 RS108A25 Clamp Nut 1
26 RS108A26 Bushing 1
27 RS108A27 Ratchet Housing 1
28 RS108A28 Roller Bearing 1
29 RS108A29 Crank Shaft 1
30 RS108A30 Drive Bushing 1
31 RS108A31 Yoke 1
*32 Washer 1
*33 Pin 1
*34 Ratchet Anvil 1
*35 Steel Ball 1
*38 Spring 2
*39 Steel Ball 2
*40 Ratchet Pawl 1
*41 Thrust Washer 1
*42 Retaining Ring 1
*43 Reverse Button 1
*44 Spring 1
*45 Lock Pin 1
*These parts available in head kit only: RSRHK100.
