Sunex Tools SX203N - Manual (Page 3)

SX203N 3 Rev. 05/02/02
SX203N
6" Quiet Dual Action Sander
Ref. # Item # DESCRIPTION QTY.
1 87513 6" DA bonded Pad (Std.) 1
2 203N02 Cap Screw 1
3 203N03 Screw Washer 1
4 203N04 Balance Nut 1
5 203N05 Wave Washer 1
6 203N06 Drive Cover 1
7 203N07 Fixing Ring 1
8 203N08 Corrugated Washer 1
9 203N09 Sanding Pad - Std. Nut 1
10 21118 Ball Bearing 1
11 203N11 Random Balance body 1
12 203N12 Lock Washer 1
13 203N13 Socket Head Cap Screw 1
14 203N14 Slotted Set Screw 1
15 203N15 Spring Washer 1
16 203N16 Front Screw 1
17 203N17 Valve Body 1
18 203N18 Front Plate 1
19 203N19 Rotor Shaft 1
20 29120 Ball Bearing 2
21 203N21 Shim 2
22 203N22 Rotor 1
23 203N23 Rotor Blade 5
24 203N24 Set Screw 1
25 203N25 Bearing Shield 1
26 203N26 Cylinder 1
Ref. # Item # DESCRIPTION QTY.
27 203N27 Set Pin 1
28 203N28 Rear Plate 1
29 203N29 Rotor Fixing Cover 1
30 203N30 Spring Washer 1
31 203N31 Rotor Screw 1
32 203N32 Muffler 1
33 203N33 Rotor Cover 1
34 203N34 Sponge 1
35 203N35 Screw 1
36 203N36 Screw 1
37 203N37 Push Rod 1
38 203N38 O-Ring 1
39 203N39 Throttle Spring 1
40 203N40 O-Ring 1
41 203N41 Throttle Valve Plug 1
42 203N42 O-Ring 1
43 203N43 Regulaor 1
44 203N44 Retaining Ring 1
45 203N45 Screw 1
46 203N46 Lever Bracket 2
47 203N47 Lever Booster 1
48 203N48 Bolt 1
49 203N49 Nut 5
50 203N50 Handle 1
51 203N51 Air Inlet 1
Note: Optional 5" DA bonded pad available as Part # 87511
