S P E C I F I C A T I O N S
4
P I N D E F I N I T I O N S
The ZB2430 has a simple interface that allows OEM Host communications with the transceiver. Table 2 below shows
the connector pin numbers and associated functions.
T a b l e 2 : P i n D e f i n i t i o n s f o r t h e Z B 2 4 3 0 t r a n s c e i v e r
SMT Pin
Pluggable
Pin
Type
Signal Name
Function
1
4
O
GIO_0
Generic Output Pin
2
6
O
GIO_1
Generic Output Pin
3
8
Do not Connect
Has internal connection, for Aerocomm use only.
4
7
I
GI0_2/ DE-RE
Generic Input pin
5
19
I
GIO_3 / AD_0
Has Internal connection. Reserved for future GPIO.
6
3
I
RXD
Asynchronous serial data input to transceiver
7
2
O
TXD
Asynchronous serial data output from transceiver
8
10
GND
GND
Signal Ground
9
1
PWR
VCC
3.0 - 3.5 V ±50mV ripple (must be connected)
10
-
PWR
VPA
3.0 - 3.5 V ±50mV ripple (must be connected)
1
11
-
GND
GND
Signal Ground
12
9
I
Test / Sleep Int.
Test Mode – When pulled logic Low and then applying power or resetting, the
transceiver’s serial interface is forced to a 9600, 8-N-1 rate. To exit Test mode,
the transceiver must be reset or power-cycled with Test Mode pulled logic
High or disconnected
Note: Because this mode disables some modes of operation, it should not be
permanently pulled Low during normal operation.
Sleep mode interrupt - When logic Low, forces End Device to wake up from
sleep mode. When logic High, allows End Device to sleep and wake-up
according to specified poll rate. Sleep mode interrupt function available on
End Devices only.
13
18
I/O
GIO_4 / AD_1
Has Internal connection. Reserved for future GPIO.
14
5
I
UP_Reset
RESET – Controlled by the ZB2430 for power-on reset if left unconnected.
After a stable power-on reset, a logic Low pulse will reset the transceiver.
15
11
I
CMD/Data
When logic Low, the transceiver interprets OEM Host data as command data.
When logic High or floating, the transceiver interprets OEM Host data as trans-
mit data.
16
20
O
In Range
When logic Low, the transceiver is associated with a parent and has been
assigned a 16-bit Network Address. The Coordinator will report In Range after
selecting a clear channel to operate.
17
16
I
RTS
Request to Send – When enabled in EEPROM, the OEM Host can take this
High when it is not ready to accept data from the transceiver. NOTE: Keeping
RTS High for too long can cause data loss due to buffer overflow.
