S
PECIFICATIONS
2
T a b l e 1 : Z B 2 4 3 0 S p e c i f i c a t i o n s
General
Interface Connector SMT or Pluggable
Antenna Chip antenna (p/n Laird MAF95029) or U.FL connector
Serial Interface Data Rate Baud rates from 110 bps to 115,200 bps. Non-standard baud rates are also supported.
Channels ZB2430-D: 15 Direct Sequence Channels
ZB2430-Q: 15 Direct Sequence Channels
Security Channelization, Network Identification and optional 128-bit AES encryption 1
Transceiver
Frequency Band 2400 - 2483.5 MHz
Channel Bandwidth 3 MHz
Channel Spacing 5 MHz
RF Data Rate (Raw) 250 kbps
Max Throughput 64kbps
RF Technology Direct Sequence Spread Spectrum
Modulation 0-QPSK
Output Power EIRP (2dBi gain antenna) ZB2430-D: -12 dBm to +5 dBm
ZB2430-Q : +2 dBm to +20 dBm
Supply Voltage 3.0 - 3.5V, ±50mV ripple
Current Draw (mA)
Note: Power down modes are not supported on
Coordinator & Router devices.
100% TX 100% RX Cyclic Sleep Deep Sleep
ZB2430-D: 25 mA 27 mA 0.5 uA 0.5 uA
ZB2430-Q: 140 mA 44 mA 7.6 uA 7.6 uA
Sensitivity (1% PER) ZB2430-D:-90 dBm typical
ZB2430-Q:-100 dBm typical
Range, Line of Site (based on 2dBi gain antenna) ZB2430-D: Up to 440 ft.
ZB2430-Q: Up to 440 ft. at +2 dBm / Up to 3.5 miles at +20 dBm
Environmental
Temperature (Operating) -40°C to 85°C
Temperature (Storage) -50°C to +85°C
Physical
Dimensions 1.0” x 1.35” x 0.22” (25.4 x 34.3 x 5.5 mm)
