WPS-750-BUL-AH Installation Manual

L/L SYNC
Line Lock Sync is used to reduce picture “roll” when the camera is
connected to an AC power supply and its picture is switched with other
cameras on a monitor.

MONITOR TYPE
Select CRT or LCD based upon the type of monitor being used to

view the camera.

FACTORY RESET
If adjustment to the camera’s settings results in poor picture quality,
it is recommended to restore the camera to factory default settings.
All configurations with the exception of the COMM SETTINGS can be

reset to factory default settings by selecting FACTORY RESET and
pressing the MENU button. This option does not have an "UNDO"

feature, so ensure default settings are desired before selecting this

function.

COMM Set
The communication setting is used to remotely
control the camera’s OSD (On-Screen Display)
from a PTZ controller or DVR through RS-485.
This is helpful for adjusting camera settings
after installation without having to be next
to the camera.
• PROTOCOL: The communication protocol is preset to PELCO-D.
This is the protocol how a PTZ controller or DVR remotely controls
the OSD.
Warning: Confirm that all devices in the system use the same Protocol.
• CAMERA ID

- CAMERA ID: Select a unique

number from 0 to 255

Warning: If multiple cameras

and devices are being used in

the surveillance system, confirm

that no other device is using the

same ID. If two or more devices

share the same ID number, the PTZ controller or DVR

will not be able to control or configure any of the devices.

PROTOCOL PELCO-D

CAMERA ID

BAUDRATE

9600

CAMRA ID

000 |------------

DISPLAY ID

OFF

ID POSITION
PREVIOUS
