WPS-750-BUL-AH Installation Manual
ECLIPSE Setting
The ECLIPSE function is used to cut off
exceptionally bright light, such as headlights
of a vehicle. Zones and sensitivity can be
adjusted based on the scene.
• AREA SETTING: Up to 16 programmable
areas can be set. Press ENTER and
EXIT to select areas. Press UP or
DOWN to turn the areas ON or OFF.
Press MENU to return to previous page.
• ALL AREA SET: Select ON to select the entire screen to cut off
bright light. Select OFF to cancel all areas.
• MASK COLOR: Change the mask color to GRAY, Dark
GRAY or BLACK.
• ECLPS LEVEL: Adjust the ECLIPSE level from 1 to 5. The larger the
value, the more sensitive the camera to the light.
• GAIN CONTROL: Turns the gain ON or OFF
• PREVIOUS: Return to previous page.
WHITE BALANCE
White Balance is the process of balancing
the color of an image so that the picture is
as accurate as possible. White balance
adjusts the image color according to the
lighting conditions of the scene. Select
one of following white balance modes:
• ATW (Auto Tracking White Balance):
ATW analyzes the color temperature of the scene and automatically
compensates to provide accurate white balance.
• COL-ROLL: This feature is used when the scene includes fluorescent
lighting and the camera has a moiré of colors in the image near
the lights.
1. CAM NAME OFF
2. LENS DC IRIS
3. EXPOSURE
4. DAY/NIGHT DAY
5. WDR/BLC/ECLPS WDR
6. WHITE BAL ATW
7. 3D-DNR ON
8. EFFECTS
9.SPECIAL
0. EXIT RET
< ECLIPSE MENU>
AREA SETTING
ALL AREA SET
OFF
MASK COLOR GRAY
ECLPS LEVEL 1 |---------------
GAIN CONTROL OFF
PREVIOUS
