13
The Rear Ports - FBR-1461
Port Description
1 PWR Connect the supplied power adapter to this jack.
2 RESET
After the router is powered on, press this reset button using the
end of paper clip or other small pointed object to reset the router
and
to restore it to factory default settings.
1. Recovery procedures for non-working routers (e.g. after a
failed firmware upgrade flash).
2. Recovery procedures for a lost web interface password:
3
LAN
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the
four LAN ports when connecting to a PC or an office/home
network of 10Mbps or 100Mbps.
4 LINE
Connect the supplied RJ-
11 (“telephone”) cable to this port when
connecting to the ADSL/Telephone network.
