22

Application Notes

INHIBIT

RUN

COAST TO

MIN SPEED

SO501 2-PIN HEADER

Use LEESON accessory plug harness

(part number: 900282.01) to mate

with 2-pin header (SO501) on control board.

Figure 7. Inhibit Plug with Run/Coast to Minimum Speed
