NXRT‐1000, NXRT‐1500, NXRT‐2000, NXRT‐3000 USER’S MANUALUNINTERRUPTIBLE POWER SUPPLY (UPS)
CAUTION
: It is very critical to connect the correct voltage EBP with the UPS intended.
EBP1 is for NXRT‐1000
EBP2 is for NXRT‐1500
EBP3 is for NXRT‐2000/3000
CONNECTING THE INCORRECT BATTERY PACK TO THE UPS MAY RESULT IN DAMAGE TO THE
UPS AND/OR BATTERY PACK WILL VOID THE WARRANTY.
All EBP’s have a different DC voltage configuration intended only for the UPS’s listed above.
PLEASE DO NOT MIX EBP’s AND MAKE SURE YOU ONLY CONNECT THE EBP TO LIKE EBP’s OR
UPS INDICATED ABOVE. DC VOLTAGES ARE MARKED ON BOTH THE UPS AND THE EBP – MAKE
SURE THEY MATCH.
