6. Start and configure the UPS
On/Off Button Function Button Inquiry Button
• Press and hold the ON/OFF button for more than 3 seconds to turn on the UPS.
The UPS should now start its inspection of the internal functions, main
synchronization, and inverter startup. Then power should start to be supplied via
the outlets. Once turned on, the UPS will perform a self‐test function, when the
yellow LED turns to green, LCD displays “on line”, and means UPS is working in
utility mode.
7. Configure the local monitoring software if desired.
• Insert the UPSilon 2000 CD (included with UPS packaging) into the CD ROM of the
local computer.
• Select “Install program” from the Autorun menu and choose for the correct
operating system.
• Follow the setup instructions. Enter the product key when prompted. The
software key is found on the CD cover. Click finish when prompted.
• The UPSILON icon will appear in the system tray of the desktop near the system
clock. Double click this icon to enlarge the program window.
• Connect the RS232 cable (included in the UPS packaging) to the Computer and
UPS. Communication should start momentarily. If it does not, click on Settings up
on the UPSilon toolbar, then select a different Comport until communication is
established.
• Click on “Manual” in the UPSILON toolbar for further software configuration.
• NOTE: PLEASE VERIFY AUTOMATIC SHUTDOWN TIME PARAMETERS IN THE
SETTINGS SECTION FOR YOUR SPECIFIC INSTALLATION.
8. Configure the optional NetAgentII SNMP card if installed.
• Insert the NetAgent Utility CD (included with SNMP packaging) into a PC and
download the user manual
• Install Netility from the AutoRun menu
• Connect a network cable from the PC to the SNMP card.
• Run Netility program and it will auto‐search and list available NetAgents (SNMP
card)
• Highlight and click “Configure” to change the network settings on the NetAgent
discovered.
• Disconnect the cable to the PC and connect the SNMP card to your network.
• Access the SNMP card via the network and make configuration changes using the
manual downloaded previously.
