Page 47
47
9.5 Motor Parts
Figure
No.
Part Name
Parts
Per
Hoist
1 Ton
2 Ton
3 Ton
1
Socket Bolt
4
90912134
2
Motor Cover Assembly
1
MR1DS1301
Brake Drum Assembly – Model MP1A
1
MP1DS5261
3
Brake Drum Assembly – Model MP1B
1
MP1DS5261R2
4
Brake Spring
1
MP1DS9264
5
Thrust Collar
1
ES506005S
6
Thrust Disc
2
ES505005S
7
Pull Rotor
1
ES503005S
8
Coned Disc Spring
1
ES504005S
Motor Shaft with Rotor – Model MP1A
1
MP1DS5291
9
Motor Shaft with Rotor – Model MP1B
1
MP1DS5291R2
10
Oil Seal
1
MR1DS9293
11
Ball Bearing
1
9001004
12
Guard
1
MR1DS9281
Motor Frame with Stator – Model MP1A
1
B1SHF10S5A2
Motor Frame with Stator – Model MP1B
1
B1SHF10S5R2
Motor Frame with Stator – Model MP1A
– w/Optional Thermal Protection
1
B1SHF10S5TP
13
Motor Frame with Stator – Model MP1B
– w/Optional Thermal Protection
1
B1SHF10S5TPR2
14
Bolt
4
9093328
15
Spring Washer
4
9012711
16
Washer
4
9012513
17
Machine Screw w/Spring Washer
1
MS555010
18
Coil Cover
1
MR1DS9326
19
Terminal Plate 6P
1
MS518010
20
Machine Screw w/Spring Washer
2
MS556010
21
Terminal Cover Packing
1
MR1GS9325
22
Terminal Cover
1
M6F206D010
23
Machine Screw w/Spring Washer
4
MS554010
24
Ball Bearing
1
E2D238125
Gear Set 80 FPM
S
1
MR1DS1241
MR1ES1241
25
Gear Set 40 FPM
L
1
MR1DL1241
MR1EL1241
26
Snap Ring
1
9047120
Gear #2 80 FPM – MODEL MP1B ONLY
S
1
MR1DS9241
27
Gear #2 40 FPM
L
1
MR1DL9241
28
Spacer
1
MR1DS9244
29
Snap Ring
1
9047120
30
Ball Bearing
1
9001211
31
O Ring
1
MR1DS9254
32
O Ring
1
9013316
33
Gear #3
1
MR1DS9242
MR1ES9242
34
Gear Box Packing
1
MR1DS9248
35
Set Pin
2
MR1DS9249
