9.1 Electric Parts
Figure
No.
Part Name
Parts
Per
Trolley
1 Ton
2 Ton
3 Ton
1
Connection Box
1
MR1DS9401
2
Connection Box Lid
1
MR1DS9411
3
Packing
1
MR1DS9421
4
Spacer
4
MS517010
5
Machine Screw
4
60704
6
Cable Holder A Assembly
1
ECP5924BB
7
Plate Assembly
1
MP1DS9447
8
Machine Screw w/Spring Washer
4
MS554010
9
Machine Screw w/Spring Washer
2
MS555010
10
Holder 46
1
ECP99BK02
11
Nut
1
9093414
12
Machine Screw w/Spring Washer
1
MS557010
13
Starter Switch Assembly
1
EP1BS2472
14
Terminal Plate 18P
1
ECP1518AE
15
Machine Screw w/Spring Washer
2
MS556010
16
Cord Cover Support Packing
1
MS527010
17
Lid 42
1
E6F630010S
18
Machine Screw w/Spring Washer
4
MS554010
Capacitor Assembly – Model MP1A
1
EP1BS2473
22
Capacitor Assembly – Model MP1B
1
MP1DS2535
23
Electromagnetic Contactor
1
MGC23306D
24
Machine Screw w/Spring Washer
2
MS556010
25
Machine Screw
4
MS554010
26
Warning Label EE
1
E2D866125
S
1
B1SHF10S9A6
B1SHF20S9A6
B1SHF30S9A6
Nameplate B – Model MP1A
L
1
B1SHF10L9A6
B1SHF20L9A6
B1SHF30L9A6
S
1
B1SHF10S9A6R2
B1SHF20S9A6R2
B1SHF30S9A6R2
Nameplate B – Model MP1B
L
1
B1SHF10L9A6R2
B1SHF20L9A6R2
B1SHF30L9A6R2
S
1
B1SHF10S9A8
B1SHF20S9A8
B1SHF30S9A8
Nameplate B (blank) – Model MP1A
L
1
B1SHF10L9A8
B1SHF20L9A8
B1SHF30L9A8
S
1
B1SHF10S9A8R2
B1SHF20S9A8R2
B1SHF30S9A8R2
27
Nameplate B (blank) – Model MP1B
L
1
B1SHF10L9A8R2
B1SHF20L9A8R2
B1SHF30L9A8R2
Nameplate C – 1/4 Ton
1
B1SHM03S9A7
28
Nameplate C – 1/2 Ton
1
B1SHM05S9A7
29
Warning Seal TM
1
T6PD0059865
30
Cable 3C Assembly
1
MP1DS2745
MP1FS2745
31
P/S Cord 4C
1
12/4
32
Cable Holder A Assembly
1
60704
33
Cable Holder A Assembly
1
60704
34
Cable Packing
2
ECP6916AA
35
Holder Plate
1
ECP5924AI
36
Plate Packing
1
ECP5924AJ
37
Cable 4C Assembly
1
MP1DS2746
MP1FS2746
38
P/B Cord 5C
1
16/6
39
Cable Holder A Assembly
1
60704
40
Cable Holder A Assembly
1
60704
41
Cable Packing
2
ECP6912AA
42
Holder Plate
1
ECP5924AI
43
Plate Packing
1
ECP5924AJ
