Harrington Hoists and Cranes SMR Trolley - Manual (Page 37)

37
9.0 1/8 to 3 Ton Parts List*
When ordering Parts, please provide the Hoist code number, lot number and serial number located on the Hoist
nameplate (see fig. below).
Reminder: Per sections 1.1 and 3.5.1 to aid in ordering Parts and Product Support, record the Hoist code number, lot
number and serial number in the space provided on the cover of this manual.
SMR Series Nameplate
The parts list is arranged into the following sections:
Section Page
9.1 Electric Parts………………………….……………………………………………..………...………... 38
9.2 Pendant Parts……………………………………………………………………………………….….. 40
9.3 Power Supply Parts…………………………………….…………………………………….….…….. 42
9.4 Side Plates and Suspension Parts…………………………………………………………....……… 44
9.5 Motor Parts…………………………………………………………….……………………….……….. 46
In the column "Parts Per Trolley" a designator is used for parts that apply only to a particular model or option.
Refer to Section 2 for SMR Trolley model numbers and additional descriptions.
The designators are:
L= Single speed, Standard, 80 fpm
S = Single Speed, Low, 40 fpm
