ASCII Characters to be Sent Out:
When sending ASCII characters to the serial port, they translate into HEXadecimal as follows. The first
eight characters are special characters unique to the FSK/RTU:
SENT SENT SENT SENT
ASCII HEX ASCII HEX ASCII HEX ASCII HEX
end-o-string 00 DLE 10 SPACE 20 0 30
LaserSearch 01 DC1 11 ! 21 1 31
pb 02 DC2 12 “ 22 2 32
blue 03 DC3 13 # 23 3 33
green 04 DC4 14 $ 24 4 34
stop 05 NAK 15 % 25 5 35
play 06 SYN 16 & 26 6 36
rewind 07 ETB 17 ‘ 27 7 37
BS 08 CAN 18 ( 28 8 38
HT 09 EM 19 ) 29 9 39
LF 0A SUB 1A * 2A : 3A
VT 0B ESC 1B + 2B ; 3B
FF 0C FS 1C , 2C < 3C
CR 0D GS 1D - 2D = 3D
SO 0E RS 1E . 2E > 3E
SI 0F VS 1F / 2F ? 3F
SENT SENT SENT SENT
ASCII HEX ASCII HEX ASCII HEX ASCII HEX
@ 40 P 50 ` 60 p 70
A 41 Q 51 a 61 q 71
B 42 R 52 b 62 r 72
C 43 S 53 c 63 s 73
D 44 T 54 d 64 t 74
E 45 U 55 e 65 u 75
F 46 V 56 f 66 v 76
G 47 W 57 g 67 w 77
H 48 X 58 h 68 x 78
I 49 Y 59 i 69 y 79
J 4A Z 5A j 6A z 7A
K 4B [ 5B k 6B { 7B
L 4C \ 5C l 6C | 7C
M 4D ] 5D m 6D } 7D
N 4E ^ 5E n 6E ~ 7E
O 4F _ 5F o 6F del 7F
