Gilderfluke&Co Z-Brick - Manual (Page 9)

IDS pin # SIGNAL
1 Data bit 0
2 Data bit 1
3 Data bit 2
4 Data bit 3
5 Data bit 4
6 Data bit 5
7 Data bit 6
8 Data bit 7
9 Address bit 0
10 Address bit 1
11 Address bit 2
12 Address bit 3
13 Address bit 4
14 Address bit 5
15 Address bit 6
16 Address bit 7
17 ground
18 ground
19 Strobe/
20 Reset/
When the address and data lines are valid, the rising edge of
the Strobe line will latch the data into the addressed outputs.
If the Z-Buss input is not going to be used, you should insert a
two position jumper between pins #17 and #19. This will tie down
any spurious outputs that might otherwise happen if the DMX-512
data is not present. The Z-Bricks ship from Gilderfluke & Co. with a
jumper in just this position.
