ted through the DMX-512 output.
The DMX-512 standard calls out a 5 pin XLR connector or screw termi-
nals for all connections. All card cages will provide either screw terminals or
other appropriate connection for attaching the DMX-512 input and output.
Edge Connector: All of the connections to and from Z-Brick Cards are
available on the 60 position edge connector. You can use an Insulation
Displacement Edge (IDE) connector if you aren’t going to be using one of
our card cages:
output wire # Edge pin # color wire function
n/a 1 brown not used
n/a 2 red not used
n/a 3 orange not used
n/a 4 yellow not used
n/a 5 green not used
n/a 6 blue not used
n/a 7 violet not used
n/a 8 gray not used
n/a 9 white not used
n/a 10 black not used
#1 11 brown J6 out channel 0 Ground
#2 12 red J6 out channel 0 bit 7
#3 13 orange J6 out channel 0 bit 6
#4 14 yellow J6 out channel 0 bit 5
#5 15 green J6 out channel 0 bit 4
#6 16 blue J6 out channel 0 bit 3
#7 17 violet J6 out channel 0 bit 2
#8 18 gray J6 out channel 0 bit 1
#9 19 white J6 out channel 0 bit 0
#10 20 black J6 out channel 0 + Supply
#11 21 brown J6 out channel 1 Ground
#12 22 red J6 out channel 1 bit 7
#13 23 orange J6 out channel 1 bit 6
#14 24 yellow J6 out channel 1 bit 5
#15 25 green J6 out channel 1 bit 4
#16 26 blue J6 out channel 1 bit 3
#17 27 violet J6 out channel 1 bit 2
#18 28 gray J6 out channel 1 bit 1
#19 29 white J6 out channel 1 bit 0
#20 30 black J6 out channel 1 + Supply
#21 31 brown J6 out channel 2 Ground
#22 32 red J6 out channel 2 bit 7
#23 33 orange J6 out channel 2 bit 6
#24 34 yellow J6 out channel 2 bit 5
#25 35 green J6 out channel 2 bit 4
#26 36 blue J6 out channel 2 bit 3
