22
Replacement Parts
See drawings on page 23.
Pump Case Parts
P21411
Case Parts (excluding Battery Case)
P21661MH Battery Pack Assembly, NiMH
P21661 Battery Pack Assembly, NiCad
P22417BC Belt Clip with screws
P22433N Keyboard Assembly
P22433R Cap Screws (set of 2)
P22433U Control Board
P22433RS2 Replacement Stack - does not include fl owmeter and fi lter housing
assemblies or motor
P22417C Exhaust Port Fitting
Pump Stack Parts
P22417D
Filter Housing Assembly
P22417E Pressure Switch Assembly
P22417F Valve Plate Assembly
P22417G Pump Body
P22417HC Diaphragm/Yoke Assembly
P22417J Regulator Assembly
P22417K Pulsation Dampener Assembly (2)
P22433L Flowmeter Assembly
Parts not indicated in illustration
P22417M
Motor/Eccentric Assembly
P22433C Tamper-resistant Cover
P22433ES External Screws
P5187 Foam Cover for control board, pk/5
P72392 LCD
Replacement Filters
P22409
Filter/O-ring, pk/3
P2240901 Filters, pk/10
P2240902 Filter/O-ring (100 fi lters/10 O-rings)
