16
4. Connect the ClockCamDVR system to a TV or an output source using the video cable
provided to properly adjust the mounting height and camera angle. Change the TV output
to the auxiliary mode, ie VIDEO 1, VIDEO2, LINE1, LINE1, and etc. depending on which
input of the television the video cable is connected into and the following user’s interface will
appear as demonstrated below.
IMPORTANT: If unsure of camera angles and projections, please proceed
to step 4 below to connect the video output to a TV or an output source to
adjust the height and camera angles to perfection before securing the system
to the wall. Be sure to test the system thoroughly for functionality before use.
It is very important for the camera angle to display the areas intended for
monitoring and recording.
Stand-by Current/Record Time/Date
Record Duration
