Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5 15
Operator's Manual
Rivers Edge® Spin Shot™
KEY # PART # DESCRIPTION QTY.
1 112ML66 WELDMENT, PLATFORM, LEFT 1
2 112ML69 WELDMENT, PLATFORM, RIGHT 1
3 112ML70 RECEIVER, LADDER 2
4 112ML71 RAIL, CURTAIN 2
5 112ML72 RAIL, UPRIGHT, SHOOTING RAIL, 40" 4
6 112ML73 WELDMENT, TREE BLADE 1
7 112ML75 TUBE, SUPPORT 58-1/2" 2
8 112ML76 BRACE, SUPPORT, TREE BLADE 2
9 112ML77 WELDMENT, FTS, SPANNER, PLATFORM 2
10 8909B BOLT 1/4-20 X 1-1/4" HHCS GR5 BLK ZN 10
11 8930B BOLT 1/4-20 X 3/4" HH GR5 BLK ZN 4
12 SL51 WELDMENT, LADDER, 4-STEP, POCKET/
PIN STYLE
1
13 17635 WELDMENT ARMREST TEARTUFF 2
14 SL52 WELDMENT, LADDER, 4-STEP, W/ VAM,
POCKET/PIN STYLE
1
15 SL78 WELDMENT, LADDER, 4-STEP W/
HOLES, POCKET/PIN STYLE
1
16 TP11 WELDMENT - SEAT POST LADDER POD 1
17 48052 WELDMENT, STABILIZER BAR, 27" 1
18 48053 TUBE, STABILIZER, SUPPORT 1
19 48057B SCREW WING 1/4-20 X 2 1/4 BLK ZN 4
20 TWR26 TUBE, RAIL SPANNER, TOWER 1
21 17630 ASSEMBLY BACKREST TEARTUFF 1
22 48662 SWIVEL ONLY - LADDER POD SEAT 1
23 48129 CAMO SLEEVE W/FOAM 128 INCH 1
24 48240B BOLT 1/4-20 X 1-1/2" HHCS GR5 BLK ZN 5
25 48250B BOLT - 1/4-20 X 1-3/4" GR5 BLK ZN 6
26 48261B WASHER FLAT 1/4" BLACK 22
27 48270B BOLT 1/4-20 X 2-1/2" HHCS GR5 BLK ZN 16
28 48271B BOLT 1/4-20 X 2-1/4" HHCS GR5 BLK ZN 4
29 48273B BOLT 1/4-20 X 3-1/4" HHCS GR5 BLK ZN 2
30 16857 ASSEMBLY SEAT TEARTUFF 1
31 48752B NUT, FLANGED, NYLOCK, 1/4-20" 47
32 48869 PLUG PIPE SQUARE 18MM 2
33 63281 LOCKPIN 1/4 X 1 3/4 ROUND HANDLE 6
34 200304 ARMREST PADDED BLK 9 IN 2
LADDER PARTS LIST
NO EXTENSIONS AVAILABLE FOR THIS MODEL.
NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT!
PART # DESCRIPTION QTY.
48086 CAMO CURTAIN 1
11984 HARNESS FAS, 30" TETHER W/SRD 1
48415 RATCHET STRAP 3
48691 TIE-OFF ROPE KIT 1
48800 DVD TREESTAND SAFETY 1
ITEMS NOT SHOWN:
Maximum Height - 17' 10" to shooting rail
Maximum Field Rating - 300 lbs.
Tree Diameter Range - 12" to 20"
