SPECIFICATIONS:
CAMERASCOPE HANDLE:
Transmission Range: Up to 10m (32.8 ft.) clear field
Transmission Frequency: 2.4GHz
Handle Dimensions: 8.5 x 6.5 x 1.9 in. (215 x 165 x 50mm)
Weight: 15 oz. (425g)
Power Source: 1 Lithium-Ion rechargeable battery (included)
CAMERA TIPPED PROBES:
12mm (0.47 in.) diameter (DCS400)
Resolution: 320 x 240 Pixels (NTSC), 704 x 576 pixels (PAL)
Depth of Field (DOF): 30 to 100mm (1.2 to 3.94 in.)
Field of View: 60°
Probe Length: 1m (3.28 ft.)
Optional 12mm Probe Extensions: 1m, 2m, 3m (3.28 ft., 6.56 ft., 9.84 ft.)
Maximum Extended Probe Length: 5m (16 ft.)
9mm (0.35 in.) diameter (DCS400-09)
Resolution: 320 x 240 Pixels (NTSC), 704 x 576 pixels (PAL)
Minimum Focus Distance: 10mm (0.5 in.)
Field of View: 60°
Probe Length: 1m (3.28 ft.)
Optional 9mm Probes: 1m, 2m, 3m (3.28 ft., 6.56 ft., 9.84 ft.)
5.5mm (0.20 in.) diameter (DCS400-05)
Resolution: 320 x 240 Pixels (NTSC), 704 x 576 pixels (PAL)
Minimum Focus Distance: 10mm (0.5 in.)
Field of View: 60°
Probe Length: 1m (3.28 ft.)
Optional 5.5mm Probes: 1m, 2m, 3m (3.28 ft., 6.56 ft., 9.84 ft.)
DETACHABLE, WIRELESS MONITOR:
Display: 3.5 in. (88.9mm) diagonal TFT LCD Color Screen
Video/Image Resolution: 320 x 240 Pixels (AVI)
Dimensions: 3.9 x 3.3 x 1.0 in. (100 x 85 x 25mm)
Weight: 6.1 oz. (172g)
Power Source: 1 Lithium-Ion rechargeable battery
CE/FCC Approvals: Yes
5
FEATURES
• 1m (3.28 ft.) long, flexible-obedient probe which is water/dust proof to IP67
standards
• 3.5 in. (88.9mm) diagonal TFT-LCD wireless color monitor can be detached
from the unit for remote viewing up to 10m (32 ft.) away. Imbedded magnets
and flip-out stand on the back of the monitor allow hands-free operation.
• 4x zoom feature • 180° image flip feature
• Both monitor and handle use rechargeable Li-ion batteries which can be
charged at the same time using the included one–into-two charging cable.
• System comes complete with batteries and charger
• Adjustable LED lights inside the tip of the probe illuminate dark spaces for
clear inspection
• View results in real-time, record video and capture/save still photos (JPEG)
• Up to 3 hours of video (AVI)
• NTSC or PAL compatible
• USB and video interconnect cables are included
• Choice of 5 menu languages: English, French, Spanish, Chinese and
Portuguese
• Optional probes or probe extensions are available for each system to extend
the reach of the camera
SYSTEM INCLUDES:
• Custom Molded Hard Case
• DCS400 CameraScope Handle
• A 1m (3.28 ft.) Long, Flexible-Obedient Probe
• Detachable, Wireless Monitor with Flip-out Stand and Built-in Magnets
• 2GB Micro SD Memory Card
• 1 Mini-Screwdriver
• USB and Video Interconnect Cables
• 2 “Li-ion” Rechargeable Batteries with AC Adapter/Charger
• The 12mm System (DCS400) comes with 3 Accessory Tools:
(45° Mirror, Magnetic Pick-Up, Pick-Up Hook)
• One-into-Two Charging Cable
• Instruction Manual
• Three Year Limited Warranty
