PRODUCT OVERVIEW
A. LCD Screen
B. Image Rotation
C. Image Zoom
D. Battery Compartment
E. ON/OFF Switch /
LED Lighting Intensity
F. Probe Connector
G. Probe
H. Camera Head
12mm Probe accessories
I. Magnetic Tip
J. Hook Tip
K. 45º Mirror Tip
4
F
D
G
Fig. 1
Fig. 2
H
A
E
B
C
I
J
K
L
N
M
5mm Probe accessories
L. Mirror
M. Thread Protector
N. Ball Guide
9.0mm Probe accessories
O. Mirror
P. Thread Protector
Q. Magnet
R. Hook
12mmProbeaccessories
5.5mmProbeaccessories
O
R
Q
P
9.0mmProbeaccessories
