Finish Thompson PFV User Manual
Page 12
ITEM
QTY
DESCRIPTION
PART NUMBER
MODEL PFM
MODEL PFP
MODEL PFV
22
1
DISCHARGE O-RING
FKM
J100991
J100991
J100991
EPDM
J102378
J102378
J102378
PERLAST
107017
107017
107017
23
1
SPOUT
1” BARB (STANDARD)
M100028-1
M100028-1
M100028-2
3/4” BARB (OPTIONAL)
105439-1
105439-1
105439
1” MNPT (OPTIONAL)
106599
106599
106599-1
24
1
DISCHARGE NUT
FOR USE WITH 1” OR 3/4” BARB SPOUT
M101610-1
M101610-1
M101610-2
FOR USE WITH 1” MNPT SPOUT ONLY
106622
106622
106622-1
25
(not
pictured)
1
MIDDLE INNER TUBE (PFM/PFP = POLYPROPYLENE, PFV = PVDF)
27” MODELS
N/A
N/A
N/A
40” MODELS
N/A
N/A
N/A
48” MODELS
N/A
N/A
N/A
60” MODELS
M100003-3
M100003-3
M100003-6
72” MODELS
M100003-3
M100003-3
M100003-6
26
(not
pictured)
1
LOWER MIDDLE INNER TUBE (PFM/PFP = POLYPROPYLENE, PFV = PVDF)
27” MODELS
N/A
N/A
N/A
40” MODELS
N/A
N/A
N/A
48” MODELS
N/A
N/A
N/A
60” MODELS
N/A
N/A
N/A
72” MODELS
M100003-1
M100003-1
M100003-5
*Recommended Spare Parts
Note: Bearing assembly and lip seal can be purchased as a kit using part number 108110.
Service 1-800-888-3743
P/N 108097-WEB, Rev 1, 3-5-13
