6
*May be two different size impellers. See below. Check model number of serial number of label to determine impeller combina-
tions. example: MSKCPCVN15C. The underline position indicates impeller combination.
1 = 3.88 + 3.88
2 = 3.5 + 3.88 3 = 3.5 + 3.5 4 = 3.19 + 3.5 5 = 3.0 + 3.5
MSKC MULTI-STAGE SPARE PARTS
Item Description
Frame
Size
Part Number
Qty.
Polypropylene PVDF
1 Impeller Housing – first stage
NPT A103195-1 A103195-2
1
BSP A103195-3 A103195-4
2
Impeller with thrust ring
2*
3.00” A101983-17 A101983-18
3.19” A101983-15 A101983-16
3.50” A101983-2 A101983-5
3.88” A101983-3 A101983-6
2A
Thrust ring – PTFE
1 3.00”/3.19” J103893
3.50”/3.88” J101606
3
Impeller drive shaft with carbon bushing
All
A103270-1 A103270-4
1 Impeller drive shaft withPTFE bushing A103270-2 A103270-5
Impeller drive shaft with ceramic bushing A103270-3 A103270-6
4
Housing o-ring – FKM All J102389
2
Housing o-ring – EPDM J102585
5 Diffuser Assembly All A103242-1 A103242-4 1
6
Diffuser o-ring – FKM
All
J102447
1
Diffuser o-ring - EPDM J102446
7 Impeller Housing – second stage NPT/ BSP 107787-1 107787-2 1
8
Impeller Drive with carbon bushing
All
A103269-1 A103269-4
1 Impeller Drive with PTFE bushing A103269-2 A103269-5
Impeller Drive with ceramic bushing A103269-3 A103269-6
8A
Impeller bushing – carbon
All
J102387
1 Impeller bushing – PTFE J102790
Impeller bushing – ceramic J103617
9 Barrier All 107788-1 107788-2 1
10 Drive Magnet Assembly
56C A101990-15
1 71/B14 A101990-13
80/B14 A101990-14
10A Set Screw – knurled point All J104219 1
10B Set Screw – cone point All J104220 1
11 Motor Adapter
56C A101991-3
1 71/B14 A101991-1
80/B14 A101991-2
12A C/S hex hd. ¼-20 x 5-1/2”LG. SS All J103873 6
12B ¼” lock washer All J100672 6
12C ¼” flat washer All J100113 6
13 Plug for motor adapter All J102878 2
14A
Motor Adapter Bolts
4 3/8-16 x 1” SS hex hd. cap screw 56C J100114
M6 x 16mm SS hex hd. cap screw 71 & 80 J102884
14B
Motor Adapter Lock Washer
4 3/8” SS lock washer 56C J100115
¼” SS lock washer 71 & 80 J100672
14C
Motor Adapter Flat Washers
4 3/8” SS flat washer 56C J100128
¼” SS flat washer 71 & 80 J100113
15
Discharge o-ring - FKM
BSP
J102391
1
Discharge o-ring - EPDM J102713
