A. Introduction
The Titan Portable Vehicle Scale (PLT-6020-XXX) is a uniquely designed truck scale,
combining the proven reliability of a hermetically sealed load cell system with the added
benefit of an above grade, low profile, portable, steel deck design scale. The Titan Series PV
scale uses a Rocker Column load cell system combined with Intalogix™ Technology.
B. Description
The Titan weighbridge consists of 35' factory assembled steel deck modules.
Each module bolts to the adjoining module. With the scale installed completely above
ground, the load cell system, suspension components and weighbridge are not subjected to
the harsh, corrosive environments found in a scale pit.
1. Rocker Column load cell systems are hermetically sealed cells completely constucted
out of stainless steel. A stainless steel sheathing protects the load cell cable.
2. Intalogix™ Technology offers the customer outstanding resolution, surge voltage
protection, and built-in diagnostics.
C. Specifications
CLC:
100,000 lbs..
Capacity:
250,000 lbs.. for a 3 section scale
300,000
lbs..
for
a
4
section
scale
Load cell data:
Capacity:
100,000 lbs.
Type:
Rocker Column
Environmental:
Stainless steel, hermetically sealed
Bridge Resistance:
1000
W
Output: 2
mV/V
Construction:
Welded structural steel I-beam
Module Design:
Orthotropic
Module Understructure:
Open
bottom
Lengths:
30’, 35’, 60’, 70’, and 80’.
