Fairbanks 6020 Titan Series User Manual
Page 13
f. SSC DIP (Address) Switch
In each of the smart SSC boxes there is an eight (8) position DIP switch labeled S1.
This switch is used to identify the section in a binary code. The switches must be
set properly for the scale to operate.
Section number
Switch settings
4
5
6
7
8
Sec 1
ON
OFF OFF OFF OFF
Sec 2 OFF
ON
OFF OFF OFF
Sec 3
ON ON
OFF OFF OFF
Sec 4 OFF
OFF
ON
OFF OFF
Note: Switches 1, 2, and 3 are always OFF. Do not change these switch settings.
Switches 4 through 8 are used to set the section address locations.
Set the section number according to the chart below.
50753
13
12/12
-- Issue 5
