A. Introduction
The Titan PV scale was designed to be used with Intalogix™ systems.
Intalogix™ systems
utilize smart sectional controllers (SSC) and pit power supplies (PPS) for load cell excitation
and signal processing.
B. Description
There is one (1) SSC per section and one (1) PPS for the entire platform unless the
number and resistance of the cells require a second pit power supply. Smart sectional
controller boxes have four (4) terminals two (2) for load cells and two (2) for interfacing to
other SSC boxes or terminating to a pit power supply. All cell/section/scale adjustments are
made via the Intalogix™ system instrument.
C. Installation
a. Boxes
The box has mounting brackets which allow mounting to adapters located inside
each load cell access hole of the Titan modules.
b. Wiring
Cable used in all wiring must be a minimum of 18 AWG. Use cable 17204 or
17246. Use appropriate service manual for the indicator being installed or refer to
the Appendix for typical wiring information.
c. Smart Sectional Controller
Wire cells into each sections sectional controller per the appropriate service
manual. Refer to the Appendix for typical wiring information.
Load Cell Wiring Designations
Color Description
Black (-) Excitation
Green (+) Excitation
Red (-) Signal
White (+) Signal
Yellow Shield
