Tools needed for assembly – Fairbanks 1100 Series Portable Utility Scale with Rechargeable battery-powered FB1100 ABS User Manual
Page 9
02/2011
9
51260 -- Rev. 1
Section 3: Description
C A U T I O N
The shipping weight of the 1100 is approximately 185 pounds.
Use caution to prevent personal injury or damage to the product.
The portable platform scale base is constructed of cast iron with cast iron levers. The
weight display is a battery-or AC-powered FB1100 Series instrument. It is equipped
with a communication port for connecting printers, displays, and/or computers.
The scale is rated at 1000 lbs. capacity with an interval or graduation size of .2 lb.
3.1. Tools needed for assembly
1. #1 (or small) slotted screwdriver
2. #2 Phillips screwdriver
3. 10” adjustable wrench
4. Common pliers
NOTE:
For commercial weighing applications, the scale must be “placed in
service” by a licensed scale technician. For a service facility near
you, please call Fairbanks Scales at 800-451-4107.
