Platform and pillar assembly – Fairbanks 1100 Series Portable Utility Scale with Rechargeable battery-powered FB1100 ABS User Manual
Page 16

02/2011
16
51260 -- Rev. 1
Section 7: Replacement parts and diagram
7.1. Platform and pillar assembly
See figure 7-1.
Item no.
Part no
Description
1
71622
Pillar rod, long
2 58933 Pillar
3 95847 Platform
cover
4 95848 Frame
5 95855 Cotter
pin
6 58937 Bearing,
platform
7
95856
Screw, Phillips head
8 95857 Screw,
Allen
9 95858 Bubble
level
10
95859
Pin, corner loop
11 71623 Loop,
corner
12
71624
Bearing, corner loop
13 71625 Cotter
pin
10, 11
58938
Loop, corner assembly
12, 13
58938
Loop, corner assembly
14 95867 Hex
nut
15
95868
Hex head bolt
16
95869
Wheel, 5” diameter
17 71628 Cotter
pin
18 71629 Washer,
flat
19 71630 Axle
24
95861
Pivot, load and fulcrum
25
72948
Short lever assembly
26
58939
Center connection assembly
31
95863
Center pivot, long lever
33 72947 Long
lever
assembly
34
95864
Long lever tip pivot
35
58934
Steelyard rod assembly
44
71592
Acorn nuts (2)
61
95865
Platform locking pin
62
95866
Cotter pin, platform locking pin
