Section 7: Replacement Parts and diagram

02/2011

18

51260 -- Rev. 1

7.2. Instrumentation kits replacement parts

See figures 7-2, 7-3, and 7-4.

Item no.

Part no

Description

1

13199

Load cell assembly

2 14237 Plate,

mounting

3 12643 “S”

hook

4

14572

Coupler, inline, telephone, 6 position, 6 pin

5

17617

Mount, cable tie

6 17613 Tie,

wire

7 20176 Bracket
8 26299 Handle

assembly

9 11263 Clip,

cable

10

13182

Screw, cap, socket head M4 x .25

11

11119

Washer, plain-flat #10

12

11092

Washer, lock-medium spring #10

13 11003 Nut-hex

10-32

14

11076

Screw, cap, hex head, 10-32 x .75

15

15716

Nut, threadlock acorn, 10-32

16

26393

Bracket, FB1100 AC adapter

17 24155 Screw,

W4 x 12, pan head

18

26395

Plate, 1100 mounting

19

30047

Instrument assembly with battery not installed FB1100 ABS

20 51260 Manual
21 13584 Shim
22

14342

Spacer, load cell

23 13099 Linkage,

cable

24

17579

Spacer, 8-32 threads x .38 lg

25

22706

Cable assembly, W1

26

11176

Bushing, Amphenol, rubber

27

10902

Screw, machine, PH-Phillips 8-32 x .38

28

10921

Washer, lock-medium, spring, #8
