Model B75 Non-Metallic Design Level 2 Page 8

2/07

Model B75 Non-Metallic Design Level 2 Page 5

Dimensions: B75 Non-Metallic
with Spill Prevention

Dimension
Standard Pump

A

B

6 9/16"

7 15/16"

Pulse Output Kit

3M Muffler
Mesh Muffler

12 11/16"

14 1/16"

13 3/4"

22 9/32"

8 13/16"

14 15/16"

Note: Porting Flanges are also available with
PN10 40mm DIN bolting configuration.

Dimensions in Inches
Dimensional tolerance: ±

1

/

8

"
