3–4
3.0 Installation
Teledyne Analytical Instruments
A Business Unit of Teledyne Electronic Technologies
WARNING: The light intensity from the quartz iodine lamp is intense and
should not be looked at directly without special protective
eyewear. Protective goggles with shaded lenses (Fed. Spec. #5)
should be worn if it is necessary to look directly at the source.
Explosion-Proof Version
See dwg. B-16571.
Control module power in:
TS2-14:
Hot
TS2-13: Neutral
TS2-12: Ground
Control module output:
TS2-1 (Com)
}
0-1 V output
TS2-2 (+)
TS2-3 (Com)
}
mA output
TS2-4 (+)
TS2-10 (Com)
}
mV output
TS2-9 (+)
TS1-1 (-)
}
mA output (isolated)
TS1-2 (+)
TS1-6 (Com)
TS1-7 (N.O.)
}
alarm relay K1
TS1-8 (N.C.)
TS1-9 (Com)
TS1-10 (N.O.)
}
alarm relay K2
TS1-11 (N.C.)
NOTE: In order to maintain the explosion-proof integrity of the system,
interconnecting wiring between the power and control modules is
performed by TAI.
General Purpose (Control Module Remote)
See dwg. C-15245.
Control Module Power In:
TS2-14:
Hot
TS2-15: Neutral
TS2-16: Ground
Power Module Power In:
TS1-1: Hot
TS1-2: Neutral
TS1-3: Ground
