Total Hydrocarbon Analyzer
Teledyne
Analytical
Instruments
vii
Table of Contents
Safety Messages ........................................................................... v
List of Figures ............................................................................... xi
List of Tables ............................................................................... xii
Additional Safety Information .................................................. xiii
Procedure for Removal of Internal Inaccessible Shock Hazards xv
Introduction ................................................................................... 1
1.1 Main Features of the Analyzer
1
1.2 Principle of Operation
2
1.3 Analyzer Description
2
1.4 Applications
3
Operational Theory ....................................................................... 7
2.1 Introduction
7
2.2 Sample System
7
2.2.1 Input Porting
8
2.2.2 Sample Flow Control System
8
2.2.3 Fuel and Blanket Air Systems
8
2.2.4 Flame Ionization Detection Cell
9
2.3 Detection Cell
9
2.3.1 Electrometer-Amplifier
10
2.3.2 Anode Power Supply
11
2.3.3 Flame Guard Circuit
11
2.3.4 Flame Ignition Circuit
11
2.3.5 Proportional Temperature Control Circuit
11
Installation ................................................................................... 13
3.1 Unpacking the Analyzer
13
