Installation Model 4020
Teledyne Analytical Instruments 24
Table 3-7: Pin out of 50 pin D-Sub Connector
pin # Description
1
2
3 + Range ID 4-20 ma
4 - Range ID 4-20 ma
5 + Output 4-20 ma
6 - Output 4-20 ma
7 - Output 0-1 v
8 + Range ID 0-1 v
9 Remote
Zero +
10 Remote Span +
11 Remote
Zero -
12 Remote Span -
13 Network
+
14 Remote Thermistor
15 Zero Solenoid Return
16 Span Solenoid Return
17 Span Solenoid Hot
18 Range 3 Contact
19 Range 3 Contact
20 Alarm 3 C Contact
21 Range 1 Contact
22 Range 2 Contact
23 - Range ID 0-1 v
24 + Output 0-1 v
25
26
27
28 Alarm 1 C Contact
29 Network
-
30 Remote Sensor +
31 Remote
Thermistor
32 Exhaust Solenoid Hot
33 Sample Solenoid Hot
34 Range 4 Contact/ not used
35 Range 4 Contact/not used
36 Alarm 3 NC Contact
37 Alarm 3 NO Contact
38 Range 1 Contact
39 Range 2 Contact
40 Calibration
Contact
