A-2
Appendix Model 3190
Teledyne Analytical Instruments
(95.3 mm H × 177.8 mm W). Face plate
rated to NEMA-4.
Sensor Type: Class A-2C, B-2C, and Z-2C
Analysis Unit: 4.0" H × 6.0" W × 2.5" D
(101.6 mm × 152.4 mm × 63.5 mm)
A.2 Spare Parts List
QTY P/N DESCRIPTION
1 C-65220-A PC Board, Main
1 C-64586 PC Board, Power Supply
1* C-6689-B-2C Micro-Fuel Cell, class B-2C
1* C-6689-Z-2C Micro-Fuel Cell, class Z-2C
2 F-1130 Fuse (AC), ½A, 250 VAC,
IEC Type T, 5 x 20mm
1 F-51 Fuse (DC), ½A, 125 VDC, Micro-Fuse
1 A-64678A Probe to Analyzer Cable, 6 ft
1* C-6689-A-2C Micro-Fuel Cell, class A-2C
* Order one type only: A-2C, B-2C, or Z-2C. See Specific Model Informa-
tion in front of this manual for cell class supplied with your analyzer.
A minimum charge is applicable to spare parts orders.
IMPORTANT: Orders for replacement parts should include the part number
and the model and serial number of the system for which the
parts are intended.
Send orders to:
Teledyne Analytical Instruments
16830 Chestnut Street
City of Industry, CA 91749-1580
Telephone: (626) 934-1500
Web Site: www.teledyne-ai.com
Fax: (626) 961-2538, (626) 934-1651
Technical Support: (626) 534-1673
Web: www.teledyne-ai.com
