3-1
Trace Oxygen Analyzer Installation 3
Teledyne Analytical Instruments
Installation
Installation of the analyzer includes:
1. Unpacking the system.
2. Mounting the Control Unit, External Sample Block, and Micro-
Fuel Cell sensor.
3. Making the electrical connections.
5. Making the gas connections.
6. Testing the installation.
CAUTIONS: Read this chapter in its entirety before installing
the units.
The Model 3190 is for or indoor use only.
The sample must be free of entrained solids or
water. However, a high humidity sample is ideal,
since it will prevent water loss from the cell
electrolyte.
The Micro-Fuel Cell sensor electrolyte is caustic.
Do not attempt to open it. Leaking or exhausted
cells should be disposed of in accordance with
local regulations. Refer to the
Material Safety Data
Sheet in the Appendix.
Any damage or scarring of the delicate permeable
membrane on the sensing end of the cell will
require cell replacement. Prevent contact with
membrane by any solid object.
3.1 Unpacking the Analyzer
As soon as you receive the instrument, carefully unpack and inspect
Control Unit, External Probe, and any included accessories for damage.
Immediately report any damage to the shipping agent. The analyzer is
Overvoltage
Category II
