MAINTENANCE

RLN-IOM-2012-1205

SECTION 4

4-6

WARNING

All information in this manual is for
reference and guidance purposes,
and does not substitute for required
professional training, conduct,
and strict adherence to applicable
jurisdictional/professional codes and
regulations.

If any manual reset limit device trips,
do not reset without determining and
correcting the cause. These include
fl ame safeguard, high or low gas
pressure, and high temperature limit.

CAUTION

All maintenance procedures should
be completed by trained personnel.
Appropriate training and instructions
are available from the Fulton Service
Department at (315) 298-5121 or your
local Fulton Representative.

14. To inspect the gasket between burner/blower mounting plate and mesh

burner undo the 4 bolts.

15. Check for cracking of the electrode insulator. Do not over tighten the

electrode.

16. Use a soft, clean cloth to remove accumulated contaminants from the UV

detector/scanner glass envelope.

17. Use a soft, clean cloth to remove accumulated contaminants from the sight

glass.

18. Before re-installing the burner, check the cleanliness of the heat exchanger

and the condition of the combustion chamber. If corrosion or leaks are
noticed, contact Fulton Heating Solutions.

19. Reverse removal steps for reinstallation of the burner assembly.

20. Reinstall side and top jacket panels.

21. Test fi re the boiler and use a combustion analyzer to ensure that the fuel/

air ratio is set correctly throughout the range. Refer to the Fulton Heating
Solutions factory test fi re report for combustion settings.

After All Repairs and Maintenance

1. Follow “Pre-Start Check List” provided with the unit, and all Safety Checks.

2. Fire the Boiler and perform combustion check. Analyze combustion

throughout the range and verify proper operation of safety devices.

3. Make any necessary adjustments.

Troubleshooting

Use the following table as a guide to troubleshooting your boiler.
