INSTALLATION
RLN-IOM-2012-1205
SECTION 2
2-4
TABLE 1A - OPERATING REQUIREMENTS
Reliance Model Size 500 750 1000 1500 2000 2500 3000
Fuel Type Natural Gas or Propane*
Input BTU/Hr Max
Min
500,000 750,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000
100,000 150,000 200,000 300,000 400,000 500,000 600,000
Electrical Requirements (Amps) (120V/60/1)
(240V/60/3) <3
NA
<3
NA
<3
NA
<6
NA
<6
NA
NA
<10
NA
<10
Water Content Gal
Liter
2.7 3 3 7.3 7.3 11 11
10.2 11.4 11.4 27.6 27.6 41.6 41.6
Dry Weight LB
KG
675 700 700 1000 1000 1400 1400
306 318 318 454 454 635 635
Operating Weight LB
KG
700 725 725 1060 1060 1492 1492
317.5 329 329 481 481 676.75 676.75
Anchor Bolt Size IN
MM
.75 .75 .75 .75 .75 .75 .75
19 19 19 19 19 19 19
Dimensions • Reliance Hydronic Boiler
Reliance Model Size 500 750 & 1000 1500 & 2000 2500 & 3000
A. Boiler Width IN 24 24 32.125 34
MM 610 609.6 815.9 863.6
B. Boiler Height IN 45 50.7 67.9 72
MM 1143 1287.8 1724.6 1828.8
C. Boiler Depth IN 29.3 29.3 34.3 42.2
MM 744.2 744.2 871.2 1071.8
D. Boiler Depth with Trim IN 43.9 43.9 49.3 55.9
MM 1115 1115 1115 1419.8
E. Air Inlet Diameter IN 4 6 8 10
MM 101.6 152.4 203.2 254
F. Flue Outlet Diameter IN 4 6 8 10
MM 101.6 152.4 203.2 254
G. Water Inlet/Outlet Size IN 2 2 2.5 3
MM 50.8 50.8 63.5 76.2
H. Min Clearance to Walls IN 1 1 1 1
MM 25.4 25.4 25.4 25.4
I. Min Clearance to Front and Rear IN 36 36 36 36
MM 914.4 914.4 914.4 914.4
J. Min Clearance to Ceiling IN 24 24 24 24
MM 609.6 609.6 609.6 609.6
TABLE 1B - BOILER DIMENSIONS (REFER TO FIGURE 1)
Notes:
Specifi cations and dimensions are approximate. We reserve the right to change specifi cations and dimensions without notice.
*The use of propane is allowable with concentration of up to 5% propylene, commonly referred to as HD5. The use of off -standard grades of propane,
such as propane HD10 (10% propylene) is not permitted unless a system is in place to reduce propylene concentration to less than 5% prior to
reaching any fuel delivery piping. This is the responsibility of the customer. Verify propylene concentration with supplier prior to commissioning and
operation of equipment.
