PINKERTON User Manual
10
PINKERTON Indicator Lights
Listed below are the use of the indicator lights when in normal operation.
Keypad
Light Light ON Light OFF Light Flashing
On-Line Dialler on line Dialler not on line Dialler had problems
Low Batt Battery Charge Voltage Low Battery OK Had Low Batt alarm
AC Fail Power not connected Power OK Had AC fail alarm
On Alarm is ON (Away mode) Alarm is OFF Alarm is ON (Home
mode)
Chime Chime Mode is ON Chime Mode is
OFF
Zone 1 - 8 Unsealed, Manual or Auto
isolated Zone is sealed Had alarm
Note that the status of the Zones will always be displayed unless disabled
by the installer. The Low Batt and AC Fail lights will show the current
state of these inputs, however the alarm (or restore) condition may have to
be present for a period before a report is initiated.
If the dialler fails to communicate, the On-Line light will remain flashing
until the next time the system is turned OFF.
All Zone lights on plus a continuous beeper
Means the keypad is locked out for 60 seconds caused by 4 consecutive
incorrect code entries.
All Zone lights flashing
Indicates a legal code has been entered (or the key pressed) and the
keypad expects another key to be pressed to select the desired function
within 10 seconds.
To cancel simply wait 10 seconds or press the key.
